This robust 1-1/4 inch one piece ball valve with 1-1/4” female NPT thread on either end for easy connection. It is manufactured using high grade 316 stainless steel. It is a reduced port design, rated at 1000 PSI, and WOG ready (Water, Oil, Gas). It is Designed to control flow on a 1-1/4” line with a simple “on” and “off” 90 degree turn of the handle. Handles can be locked in the open or closed position using a latch lock.

• Product description:
• ● 1-1/4” Female NPT Threaded, One Piece, Reduced Port Ball Valve
• Uses:
• ● Used to control flow with a "on/off" action.
• Port (Bore):
• ● Reduced Port.
• ● Scroll down to “Related Products” for Full Port options including 2-Piece and 3-Piece Options.
• Thread:
• ● 1-1/4” Female NPT Threads x 1-1/4” Female NPT Threads.
• Pressure Rating:
• ● 1000 PSI (WOG).
• Handle Type::
• ● Lever Type Handle with a locking latch.
• Handle Stem:
• ● This 1-1/4" quarter turn valve is fitted with a stem that has a Blow Out Proof Design.
• To Change the Thread:
• ● Reduce the thread using a Bushing.
• ● Convert to Male Thread using a Hex Nipple or Close Nipple.
• ● For more options to convert the 1-1/4" Female NPT thread of this shut off valve, scroll down to “Upsell Products”
• Also Called:
• ● 1-1/4" Quarter Turn Shut Off Valve
• Material of Construction:
• ● 316 Stainless Steel.

Specifications:
