• Description:
• ● A 1-1/2" three way ball valve with tri-clamp connection ends. (T-Port)
• ● Polished to a sanitary finish.
• Uses:
• ● Used as a mixing valve since it can combine flow from 2 ports and join into 1 port.
• ● 4 flow options: All 3 ports open, 2 ports open in a straight line, or any 2 ports open in an L-Formation. (See diagram below)
• ● Can allow flow in any two ports, or flow in all 3 ports.
• ● It cannot shut flow off.
• Installation:
• ● Will connect to a 1" and 1.5" Tri-Clamp Flange ends.
• Cleaning:
• ● Easy to remove for cleaning.
• ● Can be cleaned in place.
• Port:
• ● Full Port.
• Flow Pattern:
• T-Port.
• Materials:
• ● 304 Stainless Steel.

T-Port Ball Valve Flow Pattern

Specifications:

• ID: 1.375"
• Tri-Clamp Flange OD: 1.984" (1" & 1.5")
• Over All Length (OAL): 5"
