• Description:
• ● A 2-1/2" sanitary butterfly valve with 2-1/2" tri-clamp connection ends.
• ● It has a pull-trigger handle that can be locked in 3 different positions to precisely control the flow.
• ● Polished to a sanitary finish.
• Uses:
• ● Used to regulate and shut off the flow in 2-1/2" sanitary tubing.
• ● Used in hygienic applications like food processing, breweries, wineries, chemicals and pharmaceuticals.
• ● It uses a pull trigger action on the handle that when pulled releases a locking mechanism which allows the valve to be adjusted to different flow rates.
• Installation:
• ● Will connect to  2-1/2" tri-clamp flange ends.
• Cleaning:
• ● Easy to remove for cleaning.
• ● Can be cleaned in place (CIP), and is free of hidden areas for bacteria build up to occur.
• Port:
• ● Full port.
• Also called:
• ● 2-1/2" Sanitary Butterfly Valve
• Materials:
• ● Stainless Steel 304.

Specifications:

• ID: 2.375"
• Tri-Clamp Flange OD: 3.047" (2.5")
• Over All Length (OAL): 2.875"
