• Description:
• ● A 4" sanitary butterfly valve with 4" tri-clamp connection ends and an all stainless steel handle.
• ● All stainless steel squeeze-trigger handle that can be locked in 13 different positions to stop the flow or to precisely control the flow rate.
• ● Polished to a sanitary finish.
• Uses:
• ● Used to regulate and shut off the flow in 4" tubing.
• ● Often used in sanitary applications like food and beverage processing, breweries and wineries, pharmaceuticals and chemicals.
• ● It uses a squeeze action on the handle to release a locking mechanism, which allows the valve to be adjusted to different flow rates
• Installation:
• ● Will connect to 4" tri-clamp flange ends.
• Cleaning:
• ● Easy to remove for cleaning.
• ● Can be cleaned in place (CIP), has no hidden areas for bacteria build up to occur.
• Port:
• ● Full port.
• Materials:
• ● Stainless Steel 304.

Specifications:

• ID: 3.875"
• Tri-Clamp Flange OD: 4.682" (4")
• Over All Length (OAL):3.5"
