Type A adapters are used with the same size Type B, Type C, and Type D couplers and are sealed off with a Dust Cap.

• Description:
• ● Stainless Steel Male Camlock Adapter x Female NPT Thread.
• Used to:
• ● Used to couple with a Female Camlock of the same size.
• ● Used to convert a Male Thread into a Male Camlock.
• Connects to:
• ● Will connect to a Female Coupler of the same size.
• ● Will thread onto a Male NPT Thread of the same size.
• Installing:
• ● Thread the Female NPT onto a Male NPT of the same size.
• ● Then insert the Male Cam portion into a Female Coupler and close the two cam arms simultaneously.
• ● To disconnect open the cam lever arms and separate the couplings.
• Sizing:
• ● 1/2" up to 8".
• Material:
• ● Stainless Steel 304 and 316.

Dimensions:

Size(mm)	1/2′	3/4′	1′	1-1/4′	1-1/2′	2′	2-1/2′	3′	4′	6′
L1	32.5	32.5	34.5	41.5	51.5	61.5	77	67	71	82.5
L2	25	26.5	31.5	39	41.5	48	46.5	50	50	57
A1	24.5	23	26	31	39.5	48	62.5	75	102	154
A2	23.84	32.1	36.8	45.1	53.3	63	75.8	91.5	119.5	176
