This quick clean tri clamp ball valve comes with a 1" tri-clamp connection and a 3/4" ball valve for controlled flow. It is manufactured with 304 stainless steel and is also known as an easy clean tri clover ball valve.

• Description:
• ● A 3/4" Two Piece Ball Valve with a Tri-Clamp fitting holding the two body parts together.
• ● 1" or 1.5" Tri-Clover connection ends
• ● Polished to a sanitary finish.
• Uses:
• ● Easy (EZ) clean take apart ball valves are used as you would use a 3 piece ball valve.
• Installation:
• ● Will connect to 1" and 1.5" Tri-Clamp Flange ends.
• Cleaning:
• ● The 1" Quick Clean ball valve is a 3/4" two piece tri-clamp ball valve with a Tri-Clamp in the body of the valve.
• ● When this Tri-Clamp in the valve body is removed, the quick clean ball valve can now be easily be taken apart for cleaning or servicing.
• Port:
• ● Reduced Port.
• Materials:
• ● 304 Stainless Steel.

Specifications:

• ID: 0.625"
• Tri-Clamp Flange OD: 1.984" (1" & 1.5")
• Over All Length (OAL): 3.75"
