Type D couplers are used with the same size Type A, Type E, and Type F adapters and are sealed off with a Dust Plug.

• Description:
• ● Stainless Steel Female Camlock Coupler x Female NPT Thread.
• Used to:
• ● Used to couple with a Male Camlock of the same size.
• ● Used to adapt a Male Thread into a Female Camlock.
• Connects to:
• ● Will connect to a Male Adapter of the same size.
• ● Will thread onto a Male NPT Thread of the same size.
• Installing:
• ● Thread the Female NPT onto a Male NPT of the same size.
• ● Then slide the Female Cam portion over a Male Adapter and close the two cam lever arms simultaneously.
• ● To disconnect open the cam arms and separate the cam couplings.
• Sizing:
• ● 1/2" up to 8".
• Material:
• ● Stainless Steel 304 and 316.

Dimensions:

Size(mm)	1/2′	3/4′	1′	1-1/4′	1-1/2′	2′	2-1/2′	3′	4′	6′
L1	43.5	45	54.5	60.5	65	73	80	83	87	99
L2	14.5	14.5	18	20	21	24	27	30	34	36
L3	4.5	6.35	6.5	7.14	7.14	7.14	7.14	7.14	7.14	9.5
L4	25.5	27	33	38	41	45	49	49	48	55
A1	33.5	40.5	46.5	55	63.5	73.5	88	104.5	134.5	195
A2	24.5	32.7	37.8	46	54	64	76.8	92.2	120.5	177
A3	26	36.12	38.5	50.8	57.2	66	78	96	124	181
A4	14	20	25	35	40	51	61.5	76.5	102	152
